| 型号说明 |  |  |  | |||
| LM12 | LM18 | LM18 | ||||
| 检测距离 | 扩散反射型 | 10cm | 10cm(30cm) | 10cm(30cm) | ||
| 反馈反射型 | 3m | 3m | ||||
| 透过型 | 3m | 10m | 10m | |||
| 扩 散 反 射 型 | 直流 10-30V | NPN3/4-线 | No | LM12-0K1NO-KWM | LM18-0K1NO-KWM | LM18-0K1NO-ZWM |
| Ns | LM12-0K1NS-KWM | LM18-0K1NS-KWM | LM18-0K1NS-ZWM | |||
| NoorNs | LM18-0K1NP-KWM | LM18-0K1NP-ZWM | ||||
| No+Ns | LM18-0K1NS-KWM | LM18-0K1NS-ZWM | ||||
| PNP3/4-线 | No | LM12-0K1PO-KWM | LM18-0K1PO-KWM | LM18-0K1PO-ZWM | ||
| Ns | LM12-0K1PS-KWM | LM18-0K1PS-KWM | LM18-0K1PS-ZWM | |||
| NoorNs | LM18-0K1PP-KWM | LM18-0K1PP-ZWM | ||||
| No+Ns | LM18-0K1PC-KWM | LM18-0K1PC-ZWM | ||||
| 2-线 | No | LM18-0K1DO-KWM | LM18-0K1DO-ZWM | |||
| Ns | LM18-0K1DS-KWM | LM18-0K1DS-ZWM | ||||
| 交流 20-250V | 2-线 | No | LM18-0K1AO-KWM | LM18-0K1AO-ZWM | ||
| Ns | LM18-0K1AS-KWM | LM18-0K1AS-ZWM | ||||
| 交直流(20-250V) 5-线 No + Ns | ||||||
| 反 馈 反 射 型 | 直流 10-30V | NPN 3/4-线 | No | LM18-03VNO-KWM | LM18-03VNO-ZWM | |
| Ns | LM18-03VNS-KWM | LM18-03VNS-ZWM | ||||
| NoorNs | LM18-03VNP-KWM | LM18-03VNP-ZWM | ||||
| No+Ns | LM18-03VNS-KWM | LM18-03VNS-ZWM | ||||
| PNP 3/4-线 | No | LM18-03VPO-KWM | LM18-03VPO-ZWM | |||
| Ns | LM18-03VPS-KWM | LM18-03VPS-ZWM | ||||
| NoorNs | LM18-03VPP-KWM | LM18-03VPP-ZWM | ||||
| No+Ns | LM18-03VPC-KWM | LM18-03VPC-ZWM | ||||
| 2-线 | No | LM18-03VDO-KWM | LM18-03VDO-ZWM | |||
| Ns | LM18-03VDS-KWM | LM18-03VDS-ZWM | ||||
| 交流 20-250V | 2-线 | No | LM18-03VAO-KWM | LM18-03VAO-ZWM | ||
| Ns | LM18-03VAS-KWM | LM18-03VAS-ZWM | ||||
| 交直流(20-250V) 5-线 No + Ns | ||||||
| 透 过 型 | 直流 10-30V | NPN 3/4-线 | No | LM12-03TNO-KWM | LM18-10TNO-KWM | LM18-10TNO-ZWM |
| Ns | LM12-03TNS-KWM | LM18-10TNS-KWM | LM18-10TNS-ZWM | |||
| NoorNs | LM18-10TNP-KWM | LM18-10TNP-ZWM | ||||
| No+Ns | LM18-10TNS-KWM | LM18-10TNS-ZWM | ||||
| PNP 3/4-线 | No | LM12-03TPO-KWM | LM18-10TPO-KWM | LM18-10TPO-ZWM | ||
| Ns | LM12-03TPS-KWM | LM18-10TPS-KWM | LM18-10TPS-ZWM | |||
| NoorNs | LM18-10TPP-KWM | LM18-10TPP-ZWM | ||||
| No+Ns | LM18-10TPC-KWM | LM18-10TPC-ZWM | ||||
| 2-线 | No | LM18-10TDO-KWM | LM18-10TDO-ZWM | |||
| Ns | LM18-10TDS-KWM | LM18-10TDS-ZWM | ||||
| 交流 20-250V | 2-线 | No | LM18-10TAO-KWM | LM18-10TAO-ZWM | ||
| Ns | LM18-10TAS-KWM | LM18-10TAS-ZWM | ||||
| 交直流(20-250V) 5-线 No + Ns | ||||||
| 指向角 | 反馈反射型 | 1°～5° | 1°～5° | |||
| 透过型 | 3°～20° | 3°～20° | 3°～20° | |||
| 控制输出 (开关容量) | 直流三、四线 | 200mA | 200mA | 200mA | ||
| 直流二线 | 100mA | 100mA | ||||
| 交流二线 | 400mA | 400mA | ||||
| 交直流五线 | ||||||
| 响应时间:透过、反馈反射、扩散反射 | ＜5ms／＜3ms | ＜5ms／＜3ms | ＜5ms／＜3ms | |||
| 直流型:短路/极性保护 | 有/有 | 有/有 | 有/有 | |||
| 外壳材料 | ABS | ABS | 黄铜镀铬 | |||
| 防护等级 | IP67 | IP67 | IP67 | |||
| 使用环境温度 | -25℃～55℃ | -25℃～55℃ | -25℃～55℃ | |||
| 备注 | ||||||
